288W Dimmable LED Transformer – 24V | TRIAC/ELV/MLV Compatible | UL Class 2 | IP65 Rated

This dimmable LED transformer provides a powerful 288W output across three independent 96W channels, supplying a stable 24V DC for large or multi-zone low-voltage lighting systems. It supports TRIAC, ELV, and MLV dimming, making it ideal for commercial, residential, or architectural installations.

Designed for long-lasting performance, the transformer features a compact aluminum housing, IP65 rating for wet, damp, or dry locations, and integrated protection circuits against overload and short circuit. Compatible with popular dimmer brands like Lutron Diva and CL series.

🔧 Key Features:

• Output Power: 288W (96W × 3 channels)

• Output Voltage: 24V DC

• Output Current: 4A × 3

• Certification: UL, Class 2, Type HL

• Input Voltage: 120V AC | Frequency: 47–63Hz

• Dimming Compatibility: TRIAC / ELV / MLV

• Dimming Range: 0–100%

• Efficiency: 88% @ 120VAC

• Power Factor: 0.98 typical

• THD: < 20% @ full load

• Protections:

  • Short-Circuit: Hiccup mode, auto-recovery

  • Overload: Output power reduction and recovery

• Operating Temp: -40°C to +60°C

• Humidity Range: 20–95% RH

• Dimensions: 10.15" × 4.74" × 1.65"

• Wiring (18 AWG):

  • Input: Black (L), White (N), Green (GND)

  • Output: Red (V+), Blue (V–)

💡 Typical Applications:

• Multi-zone LED strip lighting

• Large-scale residential or commercial LED setups

• Architectural and landscape lighting

• LED signage and display systems

• Part Number: LA-TRF-24V-288W-C-JB-D1-C2P
