The 24V 96W CCT LED Driver with Built-In Dimmer is a high-performance constant-voltage power supply engineered for professional tunable white LED lighting systems. Combining reliable power delivery with integrated dimming technology, this driver provides precise brightness control while simplifying installation by eliminating the need for an external dimmer.
Designed with a built-in dimmer, the driver offers smooth, flicker-free dimming for enhanced lighting comfort and energy efficiency. It is also compatible with standard 3-way wall switches, allowing convenient lighting control from multiple locations—an ideal solution for residential, hospitality, retail, and commercial environments.
To ensure optimal system performance, the driver features a fine-tuning voltage adjustment knob, enabling installers to precisely calibrate the output voltage for consistent LED operation and maximum lighting performance.
With a 24V DC constant voltage output and 96W maximum power capacity, this driver is ideal for longer LED strip runs and higher-load lighting installations. It is perfectly suited for CCT tunable white LED strip lights, under-cabinet lighting, cove lighting, architectural lighting, display lighting, and other low-voltage LED applications requiring dependable performance and flexible control.
Built for durability, efficiency, and easy installation, this LED driver is an excellent choice for both new construction and retrofit lighting projects.
⭐ Key Features
- Built-In LED Dimmer
- Compatible with Standard 3-Way Wall Switches
- Fine-Tuning Output Voltage Adjustment Knob
- Constant 24V DC Output
- 96W Maximum Output Power
- Designed for CCT Tunable White LED Systems
- Smooth, Flicker-Free Dimming Performance
- Stable and Reliable Constant Voltage Output
- Compact Design for Easy Installation
- Suitable for Residential and Commercial Applications
- Ideal for LED Strip Lights, Cove Lighting, Under-Cabinet Lighting, Display Lighting, and Architectural Lighting
📐 Specifications
-
Input Voltage: 120VAC, 60Hz
-
Output Voltage: 24–26V DC (adjustable)
-
Rated Power: 96W
-
Rated Current: 4A
-
Efficiency: 91%
-
Power Factor: ≥0.99
-
THD: ≤10%
-
Flicker-Free: Yes (16kHz PWM, Gamma 2.2)
-
Dimming Range: 0.3% – 100%
-
Dimming Type: Integrated 2-in-1 (Brightness + CCT), Preset + 3-Way
-
Certifications: UL, cUL, FCC, RoHS, Class P, SELV
-
Protection: Short Circuit, Overload, Over Temperature
-
Environment: Dry and Damp Locations
- Part Number: LA-DRV-CCT-24V-96W-C-BD-S1
📏 Dimensions & Weight
-
Dimensions: 4.13" × 2.13" × 2.00" (105 × 54 × 51 mm)
-
Net Weight: 0.55 lb (0.25 kg)
